CT-PA-SSBL-343/12.7WR
ES
3926909090
| Quantity: | |
|---|---|
SPECIFICATIONS | |||||
MATERIAL: | NYLON PA 66, UL94 V2 | ||||
FEATURE: | NYLON TIE WITH STAINLESS STEEL BARB LOCKING IS DESIGNED FOR THE MOST DEMANDING APPLICATION, WHERE THE EXTRA TENSILE STRENGTH AND HIGHER RELIABILITY OF FIXING ARE REQUIRED. | ||||
COLOUR: | NATURAL OR BLACK | ||||
WORK TEMP.: | -40℃-85℃ | ||||
STANDARD: | UL | ||||
NOTE: | BLACK=BK, NATUAL=NA | ||||
EASE CODE . | LENGTH | WIDTH | THICKNESS | MAX. BUNDLE DIAMETER | MIN. TENSILE STRENGTH |
mm (inch) | mm (inch) | mm (inch) | mm (inch) | kg (1bs) | |
CT-PA-SSBL-343/12.7WR | 343 (13.5) | 12.(0.50) | 1.5(0.059) | 98(3.88) | 1112 (250) |
CT-PA-SSBL-686/12.7WR | 686(27.0) | 12.(0.50) | 1.5(0.059) | 203(8.0) | 1112 (250) |
SPECIFICATIONS | |||||
MATERIAL: | NYLON PA 66, UL94 V2 | ||||
FEATURE: | NYLON TIE WITH STAINLESS STEEL BARB LOCKING IS DESIGNED FOR THE MOST DEMANDING APPLICATION, WHERE THE EXTRA TENSILE STRENGTH AND HIGHER RELIABILITY OF FIXING ARE REQUIRED. | ||||
COLOUR: | NATURAL OR BLACK | ||||
WORK TEMP.: | -40℃-85℃ | ||||
STANDARD: | UL | ||||
NOTE: | BLACK=BK, NATUAL=NA | ||||
EASE CODE . | LENGTH | WIDTH | THICKNESS | MAX. BUNDLE DIAMETER | MIN. TENSILE STRENGTH |
mm (inch) | mm (inch) | mm (inch) | mm (inch) | kg (1bs) | |
CT-PA-SSBL-343/12.7WR | 343 (13.5) | 12.(0.50) | 1.5(0.059) | 98(3.88) | 1112 (250) |
CT-PA-SSBL-686/12.7WR | 686(27.0) | 12.(0.50) | 1.5(0.059) | 203(8.0) | 1112 (250) |
