CM-PA-MT-110/2.5A
ES
3926909090
Availability: | |
---|---|
Quantity: | |
SPECIFICATIONS | |||||
MATERIAL: | NYLON PA 66 | ||||
STANDARD: | UL (FILE NO. E223165) | ||||
EASE CODE | LENGTH | WIDTH | Max. BUNDLE DIAMETER | Min. TENSILE STRENGTH | |
1000pcs/bag | 100pcs/bag | mm (inch) | mm (inch) | mm (inch) | kg (Ibs) |
CM-PA-MT-110/2.5A | CM-PA-MT-110/2.5AC | 112(4.39) | 2.5(0.10) | 18(0.71) | 8.1(18) |
CM-PA-MT-110/2.5 | CM-PA-MT-110/2.5C | 112(4.39) | 2.5(0.10) | 18(0.71) | 8.1(18) |
CM-PA-MT-210/2.5 | CM-PA-MT-210/2.5C | 210(8.27) | 2.5(0.10) | 50(1.97) | 8.1(18) |
CM-PA-MT-100/2.5 | CM-PA-MT-100/2.5C | 100(3.94) | 2.5(0.10) | 18(0.71) | 8.1(18) |
CM-PA-MT-200/2.5 | CM-PA-MT-200/2.5C | 200(7.87) | 2.5(0.10) | 50(1.97) | 8.1(18) |
CM-PA-MT-190/4.8 | CM-PA-MT-190/4.8C | 190(7.48) | 4.8(0.19) | 46(1.81) | 22.2(50) |
CM-PA-MT-220/4.8 | CM-PA-MT-220/4.8C | 220(8.66) | 4.8(0.19) | 54(2.13) | 22.2(50) |
CM-PA-MT-270/4.8 | CM-PA-MT-270/4.8C | 270(10.63) | 4.8(0.19) | 65(2.56) | 22.2(50) |
CM-PA-MT-300/4.8 | CM-PA-MT-300/4.8C | 300(11.81) | 4.8(0.19) | 76(2.99) | 22.2(50) |
CM-PA-MT-370/4.8 | CM-PA-MT-370/4.8C | 370(14.57) | 4.8(0.19) | 102(4.02) | 22.2(50) |
CM-PA-MT2-190/4.8 | CM-PA-MT2-190/4.8C | 190(7.48) | 4.8(0.19) | 46(1.81) | 22.2(50) |
CM-PA-MT2-220/4.8 | CM-PA-MT2-220/4.8C | 220(8.66) | 4.8(0.19) | 54(2.13) | 22.2(50) |
CM-PA-MT2-270/4.8 | CM-PA-MT2-270/4.8C | 270(10.63) | 4.8(0.19) | 65(2.56) | 22.2(50) |
CM-PA-MT2-300/4.8 | CM-PA-MT2-300/4.8C | 300(11.81) | 4.8(0.19) | 76(2.99) | 22.2(50) |
CM-PA-MT2-370/4.8 | CM-PA-MT2-370/4.8C | 370(14.57) | 4.8(0.19) | 102(4.02) | 22.2(50) |
CM-PA-MT3-190/4.8 | CM-PA-MT3-190/4.8C | 190(7.48) | 4.8(0.19) | 46(1.81) | 22.2(50) |
CM-PA-MT3-220/4.8 | CM-PA-MT3-220/4.8C | 220(8.66) | 4.8(0.19) | 54(2.13) | 22.2(50) |
CM-PA-MT3-270/4.8 | CM-PA-MT3-270/4.8C | 270(10.63) | 4.8(0.19) | 65(2.56) | 22.2(50) |
CM-PA-MT3-300/4.8 | CM-PA-MT3-300/4.8C | 300(11.81) | 4.8(0.19) | 76(2.99) | 22.2(50) |
CM-PA-MT3-370/4.8 | CM-PA-MT3-370/4.8C | 370(14.57) | 4.8(0.19) | 102(4.02) | 22.2(50) |
