Pre-insulated Terminals: the Wire Range Standard Cross-reference

Views:23     Author:Site Editor     Publish Time: 2016-12-15      Origin:Site

Wire Range   Standard Cross-reference Sheet

Standard (绝缘端子标准)

JIS (日本标准)

DIN (德国标准)

GB (国标)

AWG
  (
美国线规)

接线规格
  Wire Range (AWG)

接线范围
  Wire Range (mm²)

接线规格
  Wire Range (AWG)

接线范围
  Wire Range (mm²)

接线规格

Wire Range (AWG)

接线范围

Wire Range (mm²)

GB.WE

0.5

0.2-0.5

0.5

0.1-0.4

0.5

0.1-0.5

0.1-0.5

26-22

1.25

0.25-1.63

1.25

0.25-1.65

1

0.5-1.5

0.5-1.5

22-16

2

1.04-2.63

2

1.04-2.63

2.5

1.5-2.5

2.5

16-14

3.5

2.63-4.60

3.5

2.63-4.6



4

14-12

5.5

2.63-6.64

5.5

2.63-6.64

6

4.0-6.0

6

12-10

8

6.64-10.52

8

6.64-10.52

10

10

10

8

14

10.52-16.78

14

10.52-16.78

16

16

16

6

22

16.78-26.66

22

16.78-26.66

25

25

25

4

38

26.66-42.42

38

26.66-42.42

35

35

35

2

50

38.5-59.7


38.5-59.7

50

50

50

1

60

42.42-60.57

60

42.42-60.57



60

1/0

70

60.57-76.28

70

60.57-76.58

70

70

70

2/0

80

76.28-96.30

80

76.28-96.30

95

95

95

3/0

100

96.30-117.2

100

96.30-117.20

120

120

120

4/0

150

117.2-152.05

150

117.20-152.05

150

150

150

250-300MCM

185

152.05-192.6

180

152.05-192.6

185

185

185

300-350MCM

200

192.6-242.27

200

192.6-242.27

240

240

240

400-500MCM

325

242.27-352.0

325

242.27-352.0

300

300

300

500-600MCM





Stud size

#2

#3

#4

#6

#8

#10

1/4

5/16

3/8

in.

.087

.106

.126

.146

.169

.209

.252

.331

.413

mm

2.2

2.7

3.2

3.7

4.3

5.3

6.4

8.4

10.5











Stud size

7/16

1/2

9/16

5/8

11/16

3/4

7/8

15/16

1''

in.

.453

.512

.591

.669

.748

.827

.906

.984

1.102

mm

11.5

13.0

15.0

17.0

19.0

21.0

23.0

25.0

28.0
