SS-SP-8BA
ES
73269019
| Quantity: | |
|---|---|
SPECIFICATIONS | ||||||
MATERIAL: | STAINLESS STEEL 304 OR 316 | |||||
FEATURE: | NON-FLAMMABILITY | |||||
HIGH RESISTANCE TO ACETIC ACID, | ||||||
ALKALI ACID, SULPHURIC ACID, ECT | ||||||
WORK TEMP.: | -60℃～150℃FOR BARE TYPE | |||||
-40℃~85℃ FOR COATED TYPE | ||||||
EASE CODE . | TYPE | THICKNESS | WIDTH | PACKING | FIT BUCKLE | SUIT TOOL |
mm(inch) | mm(inch) | meters | ||||
SS-SP-8BA | BARE | 0.3(0.011) | 8(0.315) | 50 | SS-BK-8L | SS-TO-G |
SS-SP-10BA | BARE | 0.3(0.011) | 10(0.394) | 50 | SS-BK-10L | SS-TO-G |
SS-SP-12BA | BARE | 0.4(0.016) | 12(0.472) | 25 | SS-BK-12L; SS-BK-12O | SS-TO-B;SS-TO-A |
SS-SP-15BA | BARE | 0.4(0.016) | 15(0.590) | 25 | SS-BK-15L; SS-BK-15O | SS-TO-B;SS-TO-A |
SS-SP-8EP | EPOXY COATED | 0.3(0.011) | 8(0.315) | 50 | SS-BK-8L | SS-TO-G |
SS-SP-10EP | EPOXY COATED | 0.3(0.011) | 10(0.394) | 50 | SS-BK-10L | SS-TO-G |
SS-SP-12EP | EPOXY COATED | 0.4(0.016) | 12(0.472) | 25 | SS-BK-12L; SS-BK-12O | SS-TO-B;SS-TO-A |
SS-SP-15EP | EPOXY COATED | 0.4(0.016) | 15(0.590) | 25 | SS-BK-15L; SS-BK-15O | SS-TO-B;SS-TO-A |
SS-SP-9EP | PVC COATED | 1.0(0.040) | 9(0.354) | 25 | SS-BK-9L | SS-TO-G |
SS-SP-13EP | PVC COATED | 1.2(0.047) | 13(0.512) | 20 | SS-BK-13L; SS-BK-13O | SS-TO-B;SS-TO-A |
SS-SP-16EP | PVC COATED | 1.2(0.047) | 16(0.063) | 20 | SS-BK-16L; SS-BK-16O | SS-TO-B;SS-TO-A |
