200℃ Heat-Shrink Fluoroelastomer Tubing
You are here: Home » Product Category » Heat Shrink Tubes » Heat Shrink Kynar Tubing » 200℃ Heat-Shrink Fluoroelastomer Tubing

Product Categories

Share to:

200℃ Heat-Shrink Fluoroelastomer Tubing

SPECIFICATIONS
MATERIAL: FLUOROELASTOMER
FEATURE: FLEXIBLE, FLAME RETARDANT
WALL TYPE: SINGLE
SHRINK TEMP: 175℃
WORK TEMP: -40℃-200℃

  • HS-FE-2X
  • ES
  • 3917320000
Quantity:

200℃ Heat-Shrink Fluoroelastomer Tubing


SPECIFICATIONS

MATERIAL:

FLUOROELASTOMER

FEATURE:

FLEXIBLE, FLAME RETARDANT

WALL TYPE:

SINGLE

SHRINK TEMP:

175℃

WORK TEMP:

-40℃-200℃

EASE CODE

AS SUPPLIED (mm)

AFTER RECOVERY (mm)

STANDARD LENGTH

INSIDE DIAMETER

WALL THICHNESS

INSIDE DIAMETER

WALL THICHNESS

(D)

(T)

(d)

(t)

M/Spool

HS-FE-3.2/1.6

≥3.2

0.38±0.10

≤1.6

0.76

50

HS-FE-4.8/2.4

≥4.8

0.45±0..10

≤2.4

0.89

50

HS-FE-6.4/3.2

≥6.4

0.45±0..15

≤3.2

0.89

50

HS-FE-9.5/4.7

≥9.5

0.51±0..18

≤4.7

1.02

50

HS-FE-12.7/6.4

≥12.7

0.61±0..18

≤6.4

1.22

30

HS-FE-15.9/7.9

≥15.9

0.70±0..20

≤7.9

1.4

30

HS-FE-19.1/9.5

≥19.0

0.73±0..20

≤9.5

1.45

30

HS-FE-22.2/11.1

≥22.2

0.76±0..22

≤11.1

1.53

30

HS-FE-25.4/12.7

≥25.4

0.89±0.25

≤12.7

1.78

30

HS-FE-31.8/15.9

≥31.8

0.96±0.28

≤15.9

1.91

30

HS-FE-38.1/19.1

≥38.1

1.20±0.30

≤19.1

2.41

15

HS-FE-51.8/25.4

≥51.8

1.40±0.40

≤25.4

2.79

15

Standard colour: Black. Other sizes are available upon request. The data above are for reference only.


Technical Date

PROPERTY

DATA

CONDITION

Min. Shrink Temperature

175℃


Operation Temperature

-55℃-200℃

IEC216

Tensile Strength

≥8MPa

ASTM D638

Elongation Change

≥250%

ASTM D638

Longitudinal Change

≤10%


Elongation Change After Aging At 168hrs, 250℃

≥200%


Heat Shock At 4hrs, 300℃

No Cracking or Dripping


Dielectric Strength

≥9kV /mm

ASTM D2671

Volume Resistivity

≥1.0*1011Ω-cm

ASTM D876
