CF-PA-TL-5
ES
3926909090
| Quantity: | |
|---|---|
SPECIFICATIONS | |||
MATERIAL: | NYLON PA66,UL94 V2 | ||
FEATURE: | REUSABLE AND RELEASABLE FOR EASY WIRE BUNDING. EASY OPEN-AND-TWIST TO CABLES | ||
COLOUR: | NATURAL (STANDARD) | ||
EASE CODE . | Φ | LENGTH | BUNDLE DIA. |
mm (inch) | mm (inch) | mm (inch) | |
CF-PA-TL-5 | Φ5.2(0.205) | 21.0(0.827) | ~4.5(0.177) |
CF-PA-TL-8 | Φ8.3(0.327) | 25.2(0.992) | ~7.3(0.287) |
CF-PA-TL- 11 | Φ11.5(0.453) | 30.9(1.217) | ~10.5(0.413) |
CF-PA-TL- 15 | Φ15.0(0.591) | 35.1(1.382) | ~14.0(0.551) |
CF-PA-TL-18 | Φ18.0(0.709) | 40.0(1.575) | ~17.0(0.669) |
CF-PA-TL- 19 | Φ19.5(0.768) | 42.5(1.673) | ~19.0(0.748) |
CF-PA-TL- 22 | Φ22.5(0.886) | 45.5(1.791) | ~22.0(0.866) |
SPECIFICATIONS | |||
MATERIAL: | NYLON PA66,UL94 V2 | ||
FEATURE: | REUSABLE AND RELEASABLE FOR EASY WIRE BUNDING. EASY OPEN-AND-TWIST TO CABLES | ||
COLOUR: | NATURAL (STANDARD) | ||
EASE CODE . | Φ | LENGTH | BUNDLE DIA. |
mm (inch) | mm (inch) | mm (inch) | |
CF-PA-TL-5 | Φ5.2(0.205) | 21.0(0.827) | ~4.5(0.177) |
CF-PA-TL-8 | Φ8.3(0.327) | 25.2(0.992) | ~7.3(0.287) |
CF-PA-TL- 11 | Φ11.5(0.453) | 30.9(1.217) | ~10.5(0.413) |
CF-PA-TL- 15 | Φ15.0(0.591) | 35.1(1.382) | ~14.0(0.551) |
CF-PA-TL-18 | Φ18.0(0.709) | 40.0(1.575) | ~17.0(0.669) |
CF-PA-TL- 19 | Φ19.5(0.768) | 42.5(1.673) | ~19.0(0.748) |
CF-PA-TL- 22 | Φ22.5(0.886) | 45.5(1.791) | ~22.0(0.866) |
