CT-PA-BH-200/7.6
ES
3926909090
| Quantity: | |
|---|---|
SPECIFICATIONS | ||||
MATERIAL: | NYLON PA 66, UL94 V2 | |||
FEATURE: | USED FOR NORMAL BUNDLING AND THROUGH-PANEL APPLICATIONS. | |||
SMALL HEAD HEIGHT ALLOWS MORE EFFICIENT USE OF SPACE IN COMPACT AREAS. | ||||
RELEASABLE PRIOR TO FINAL TENSIONING FOR BUNDLE MODIFICATIONS. | ||||
COLOUR: | NATURAL OR BLACK( STANDARD) | |||
STANDARD: | UL (File No.E223165) | |||
OPTION: | OTHER COLOURS ARE AVAILABLE UPON REQUEST | |||
NOTE: | BLACK=BK，NATURAL=NA，YELLOW=YW， SILVER=SV， RED=RD， BLUE=BL | |||
EASE CODE . | LENGTH | WIDTH | MAX. BUNDLE DIAMETER | MINIMUM TENSILE STRENGTH |
100PCS/bag | mm (inch) | mm (inch) | mm (inch) | Kg(lbs) |
CT-PA-BH-200/7.6 | 200(7.87) | 7.6(0.30) | 50(1.97) | 65(144) |
CT-PA-BH-370/7.6 | 370(14.57) | 7.6(0.30) | 101(3.98) | 65(144) |
SPECIFICATIONS | ||||
MATERIAL: | NYLON PA 66, UL94 V2 | |||
FEATURE: | USED FOR NORMAL BUNDLING AND THROUGH-PANEL APPLICATIONS. | |||
SMALL HEAD HEIGHT ALLOWS MORE EFFICIENT USE OF SPACE IN COMPACT AREAS. | ||||
RELEASABLE PRIOR TO FINAL TENSIONING FOR BUNDLE MODIFICATIONS. | ||||
COLOUR: | NATURAL OR BLACK( STANDARD) | |||
STANDARD: | UL (File No.E223165) | |||
OPTION: | OTHER COLOURS ARE AVAILABLE UPON REQUEST | |||
NOTE: | BLACK=BK，NATURAL=NA，YELLOW=YW， SILVER=SV， RED=RD， BLUE=BL | |||
EASE CODE . | LENGTH | WIDTH | MAX. BUNDLE DIAMETER | MINIMUM TENSILE STRENGTH |
100PCS/bag | mm (inch) | mm (inch) | mm (inch) | Kg(lbs) |
CT-PA-BH-200/7.6 | 200(7.87) | 7.6(0.30) | 50(1.97) | 65(144) |
CT-PA-BH-370/7.6 | 370(14.57) | 7.6(0.30) | 101(3.98) | 65(144) |
