CT-PA-PM-110/2.5
ES
3926909090
| Quantity: | |
|---|---|
SPECIFICATIONS | ||||
MATERIAL： | NYLON PA 66 | |||
STANDARD： | UL (FILE NO. E223165) | |||
COLOUR: | NATURAL OR BLACK (STANDARD) | |||
OPTION: | OTHER COLOURS ARE AVAILABLE UPON REQUEST | |||
EASE CODE | LENGTH | WIDTH | Max. BUNDLE DIAMETER | Min. TENSILE STRENGTH |
100pcs/bag | mm (inch) | mm (inch) | mm (inch) | kg (Ibs) |
CT-PA-PM-110/2.5 | 110 (4.33) | 2.5 (0.10) | 22 (0.87) | 8.1 (18) |
CT-PA-PM-130/3.2 | 130 (5.12) | 3.2 (0.13) | 28 (1.10) | 13.6 (30) |
CT-PA-PM-130/4.8 | 130 (5.12) | 4.8 (0.19) | 25 (0.98) | 22.2 (50) |
CT-PA-PM-170/4.8 | 170 (6.69) | 38 (1.50) | ||
CT-PA-PM-190/4.8 | 195(7.68) | 45 (1.77) | ||
CT-PA-PM-150/3.6 | 150 (5.91) | 3.6 (0.14) | 32 (1.26) | 13.6 (30) |
CT-PA-PM-200/4.8 | 200(7.87) | 4.8 (0.19) | 46 (1.81) | 22.2 (50) |
