Heat - Shrink Heavy-Wall 3X Tubing
You are here: Home » Product Category » Heat Shrink Tubes » Heat Shrink Dual-wall Tubing » Heat - Shrink Heavy-Wall 3X Tubing

Product Categories

Share to:

Heat - Shrink Heavy-Wall 3X Tubing

SPECIFICATIONS
MATERIAL: POLYOLEFIN (CROSSLINKED)
STANDARD: UL 224 110°C & RoHS
SHRINK TEMP: 120°C
WORK TEMP: -55°C~110°C
WALL TYPE: HEAVY
RATIO: 3:1
UL FILE: E197895

  • HS-HW-3X
  • ES
  • 3917320000
Quantity:

Heat - Shrink Heavy-Wall 3X Tubing


SPECIFICATIONS

MATERIAL:

POLYOLEFIN (CROSSLINKED)

STANDARD:

UL 224 110°C & RoHS

SHRINK TEMP:

120°C

WORK TEMP:

-55°C~110°C

WALL TYPE:

HEAVY

RATIO:

0.12569

UL FILE:

E197895

EASE CODE

AS SUPPLIED (mm)

AFTER RECOVERY (mm)

Inside

Inside

Total Wall

STANDARD LENGTH

Diameter

Diameter

Thickness

(D)

   (d)

(t)

(m/pc)

HS-HW-9/3

≥9.0

≤3.0

≥2.0

1.22

HS-HW-13/4

≥13.0

≤4.0

≥2.4

1.22

HS-HW-22/6

≥22.0

≤6.0

≥2.7

1.22

HS-HW-33/8

≥33.0

≤8.0

≥3.2

1.22

HS-HW-40/12

≥40.0

≤12.0

≥4.1

1.22

HS-HW-55/16

≥55.0

≤16.0

≥4.1

1.22

HS-HW-65/19

≥65.0

≤19.0

≥4.1

1.22

HS-HW-75/22

≥75.0

≤22.0

≥4.1

1.22

HS-HW-85/25

≥85.0

≤25.0

≥4.3

1.22

HS-HW-95/30

≥95.0

≤30.0

≥4.3

1.22

HS-HW-105/34

≥105.0

≤34.0

≥4.3

1.22

HS-HW-130/36

≥130.0

≤36.0

≥4.3

1.22

HS-HW-160/50

≥160.0

≤50.0

≥4.3

1.22

HS-HW-180/50

≥180.0

≤50.0

≥4.3

1.22

HS-HW-200/60

≥200.0

≤60.0

≥4.3

1.22

NOTE: SINGLE-WALL OF HEAT-SHRINK HEAVY WALL 3X TUBING IS ALSO AVAILABLE UPON REQUEST
